Description
Whirlpool Dishwasher 24″ Width 55dB 2 Loading Racks WDP540HAMZ
New Open Box
| Specification | Value |
|---|---|
| Capacity | 12 place settings |
| Width | 23-7/8 inches |
| Height | 33-1/2 inches |
| Depth | 24-1/2 inches |
| Depth with Door Open 90° | 49-1/2 inches |
| Cutout Width | 24 inches |
| Cutout Height | 34 inches |
| Cutout Depth | 24 inches |
| Product Width (alternate listings) | 23.875 – 23.90 inches |
| Product Height (alternate listings) | 33.5 – 34 inches |
| Product Depth (alternate listings) | 24.5 – 25 inches |
| Net Weight | 69 lbs |
| Gross Weight | 80 lbs |
| Style / Type | 24″ built-in, fully integrated dishwasher |
| Color / Finish | Fingerprint Resistant Stainless Steel |
| Handle Type | Long pocket handle |
| Door Style | Flat |
| Control Location | Top (hidden controls) |
| Control Type | Electronic touch |
| Status Light | Blue |
| Sound Level | 55 dBA |
| Energy Star Qualified | No |
| CEE Tier Rating | Tier I |
| NSF Certified | Yes |
| ADA Compliant | No |
| Eco Series | Yes |
| Number of Wash Cycles | 5 |
| Dishwasher Cycle Selection | Boost, Extended Soak, Heavy, Normal, Quick Wash |
| Dishwasher Option Selections | Extended Dry, Heated Dry, Hi Temp Wash, Sani Rinse |
| Drying System Type | Heating element |
| Built-in Water Softener | No |
| Number of Racks | 2 |
| Tub Style | Built-in Tall Tub 24″ |
| Tub Material | Plastic tub with stainless steel interior door (hybrid tub) |
| Interior Color | Dark gray plastic tub with stainless steel door |
| Rack Material | Nylon |
| Dishwasher Rack Material (marketing) | Nylon |
| Number of Wash Levels | 4 |
| Number of Wash Arms | 2 |
| Wash System Type | Removable filter |
| Water Filtration | Yes – Triple Filtration Wash System |
| Triple Filtration Wash System | Coarse, fine, and micro-fine filters to capture large, medium, and small food particles |
| Boost Cycle | Yes – uses more water, time, and heat than Normal, less time than Heavy |
| Extended Soak Cycle | Yes – helps dissolve stuck-on food |
| Quick Wash Cycle | Yes – fast cleaning for lightly soiled items |
| Heavy Cycle | Yes |
| Normal Cycle | Yes |
| Extended Dry Option | Yes – elevates drying performance |
| Heated Dry Option | Yes |
| Hi Temp Wash Option | Yes |
| Sani Rinse Option | Yes |
| Leak Detect / Leak Detection | Yes |
| Dispensers | Detergent and rinse aid |
| Rinse Aid Dispenser Level Indicator | Optical level indicator |
| Automatic Temperature Controls | Yes |
| Last Cycle Recall | Yes |
| Sound Package | Quiet Pack |
| Interior Light | No (some third-party listings incorrectly say Yes) |
| Three 5″ Cup Shelves | Yes – fit six additional cups or small bowls; fold down when not in use |
| Silverware Basket Type | Full-length, non-splittable basket |
| Silverware Basket Location | Lower rack – right side |
| Silverware Basket Covers | Yes |
| Lower Rack Glides | Wheels |
| Second Level Rack Extras | 3 plastic cup shelves |
| Second Level Rack Adjustable | No |
| Fold-Down Tines (Upper / Lower) | No |
| Cushion-Tip Tines | No |
| Tall Tub | Yes |
| Wi-Fi / Smart Appliance | No |
| Works with Alexa / Google Assistant | No |
| Accepts Custom Panels | No |
| Hard Food Disposer | Not listed (uses filtration system instead) |
| Delay Wash | Not listed |
| Steam Wash | No |
| Sabbath Mode | No |
| Kosher Consumer Friendly | No |
| Power Cord Included | No |
| Voltage | 120 V |
| Amps | 15 A |
| Motor Horsepower | Approx. 0.075 HP |
| WiFi Connected (marketing field) | No |
| Console | Integrated |
| Noise Level (alternate listing) | 55 dBA |
| Place Settings (capacity field) | 12 |
WARRANTY
| 1 YEAR PARTS & LABOUR WARRANTY | Yes |
