| Specification |
Value |
| Type |
Built-in dishwasher |
| Series |
100 Series |
| Model |
SHE3AEM5N |
| Color / Finish |
Stainless Steel Anti-fingerprint (Brushed steel anti-fingerprint) |
| Capacity |
14 place settings |
| Width |
23 9/16 inches (23.54–23.56″ nominal / 598 mm) |
| Height |
33 7/8 inches (33.86–33.88″ / 860 mm) |
| Depth |
22 9/16 inches (22.56–22.75″ without handle / ~573 mm) |
| Required Cutout – Width |
24 inches |
| Required Cutout – Height |
33 7/8 inches |
| Required Cutout – Depth |
24 inches |
| Overall Appliance Dimensions (HxWxD) |
33 7/8″ x 23 9/16″ x 22 9/16″ (860 x 598 x 573 mm) |
| Net Weight |
Approx. 71–76 lb (32.2–34.5 kg) |
| Sound Level |
50 dBA |
| Installation Type |
Built-under, built-in |
| Door Panel Type |
Solid front control (fully visible front panel) |
| Control Type |
Electronic / digital, front control |
| Display |
Yes |
| Tub Material |
Stainless steel with Polinox / polypropylene base |
| Tall Tub |
No |
| Racks |
2 racks (no 3rd rack) |
| Rack Material |
Nylon |
| Adjustable Upper Rack |
No |
| Cutlery Holder / Basket |
Yes (basket; no cutlery tray / 3rd rack) |
| Interior Light |
No |
| Drying System |
PureDry® (inherent heat, condensation drying) |
| Leak Protection |
24/7 Overflow Protection System® (leak protection) |
| NSF® Certified Sanitize Option |
Yes |
| Water Softener |
No |
| Maximum Water Inlet Temperature |
140 °F (60 °C) |
| Number of Place Settings (EU / IEC) |
14 |
| Number of Programs / Cycles |
5 main cycles (Heavy, Auto, Normal, Speed60, Favorite) plus downloadable cycles via Home Connect |
| List of Programs (onboard) |
Heavy, Auto, Normal, Speed60 (1 hr), Favorite / MyCycle |
| Downloadable / Connected Cycles |
Delicate, Rinse / Rinse & Hold, Machine Care, Eco, Half Load (via Home Connect) |
| Number of Wash Temperatures |
4 |
| Options (onboard) |
Sanitize, ExtraDry, Remote Start |
| Additional Options via Home Connect |
Half Load, Eco and other downloadable options |
| Special Functions / Technologies |
PrecisionWash® sensor wash, Extra Dry, HygienePlus (sanitize), Remote Start, leak sensor, concealed heating element |
| Cleaning System |
PrecisionWash® with multiple spray levels, EcoSilence Drive, Aquasensor |
| Detergent Tray |
Dedicated detergent tray for tabs |
| Status Indicator |
End-of-program audible signal; time remaining indicator on front (on some regional variants) |
| Control Lock / Child Lock |
Yes (button suspension) |
| ENERGY STAR® Certified |
No |
| Estimated Annual Energy Consumption |
269 kWh/year |
| Total Annual Water Consumption |
753 gallons/year (typical) |
| Water Consumption (per cycle, typical ranges) |
Approx. 2.4–6.4 gallons depending on program |
| Voltage |
120 V |
| Frequency |
60 Hz |
| Amps |
12 A |
| Connected Load |
1,440 W |
| Power Cord Length |
67 inches (170 cm); 3-prong cord included |
| Drain Hose Length |
90 1/2 inches (with optional extension available) |
| Adjustable Feet / Leveling Legs |
Yes – all feet adjustable |
| Panel Ready |
No |
| Removable Top |
No |
| Variable Hinge |
No |
| Home Connect™ (Wi‑Fi) |
Yes – Remote Monitoring and Control, downloadable cycles, notifications |
| Smart Home Compatibility |
Works with Bosch Home Connect app; some retailers list Alexa / Google compatibility via Home Connect |
| Voice Control |
Not natively; may be available via Home Connect integrations (varies by region) |
| Safety Listings / Certifications |
CSA safety listing (Canada); NSF® sanitize |
| Fingerprint Resistant |
Yes (anti-fingerprint stainless steel) |
