Description
Bosch 500 Series 24″ Width 44 dB 3 Loading Racks SHP65CC5UC
New Open Box
| Specification | Value |
|---|---|
| Brand | Bosch |
| Series | 500 Series |
| Model | SHP65CC5UC |
| Product Type | Built-in dishwasher |
| Installation Type | Built-under |
| Panel Ready | No (panel not possible) |
| Door Panel | Not panel-ready, pocket handle |
| Color | Stainless Steel Anti-fingerprint (Brushed Steel Anti-Fingerprint) |
| Handle Type | Pocket handle |
| Control Type | Electronic, push-button |
| Control Location | Top control (hidden) |
| Control Panel Color | Stainless steel |
| Place Settings | 15 place settings (some retailers list 16; Bosch spec: 15) |
| Third Rack | Flexible 3rd Rack (3rd Rack 2.0) |
| Silverware Basket | Yes |
| Rack System | EasyGlide™ rack system on all three racks |
| Upper Rack Adjustability | RackMatic® 3-stage, 9 possible positions |
| Basket with Handle | Top and bottom baskets with handles |
| Tub Material | Stainless steel |
| Interior Light | No |
| Silence Rating | 44 dB(A) |
| Sound Package / Motor | EcoSilence Drive |
| Overall Height | 34 1/16 inches |
| Overall Width | 23 9/16 inches |
| Overall Depth (cabinet depth) | 22 9/16 inches |
| Class Width | 24 inches |
| Depth (without handle) | 22.56 inches (approx. 22 9/16 inches) |
| Actual Width | 23.56 inches (approx. 23 9/16 inches) |
| Height (minimum, adjustable) | 34.06 inches |
| Required Cutout Height | 34 1/16 – 34 1/8 inches |
| Required Cutout Width | 24 inches |
| Required Cutout Depth | 24 inches |
| Depth with Door Open | 47.44 inches |
| Net Weight | Approx. 92–95 lb (Bosch spec ~93 lb) |
| Adjustable Feet | Yes, all adjustable from front |
| Number of Wash Cycles (control panel) | 5 (Heavy, Auto, Normal, Express/Quick, Favorite) |
| Additional Cycles via Home Connect | 3 (Delicate/Hand Wash, Rinse, Machine Care; some sites also list Energy Save, Half Load as program/option) |
| Total Number of Programs (incl. app) | Up to 8 |
| Options on Control Panel | 3 (Sanitize, Remote Start, Extra Dry) |
| Additional Options via Home Connect | Half Load, Eco / HygienePlus and other downloadable options depending on region |
| Total Number of Options | 5 |
| Drying System | PureDry® condensation drying |
| Washing System | PrecisionWash® with multiple spray levels |
| Number of Wash Levels | Five-level wash |
| Sanitize Option | Yes (NSF®-certified sanitize option; some retailer specs omit NSF but Bosch lists sanitize) |
| Leak Protection | 24/7 AquaStop® Plus leak protection system |
| Water Softener | Yes |
| Maximum Water Hardness | Up to 50 °dH |
| Maximum Inlet Water Temperature | 140 °F |
| Home Connect™ (Wi‑Fi) | Yes, remote monitoring and control |
| Smart Features | Remote start, cycle status, program downloads, notifications |
| Software Update Capability | Yes (via Home Connect) |
| Energy Consumption (annual) | 269 kWh/year (approx.) |
| ENERGY STAR® Certification | Not ENERGY STAR® certified in some listings |
| Estimated Water Use per Cycle | Approx. 2.3 gallons (where listed) |
| Voltage | 120 V |
| Frequency | 60 Hz |
| Current | 12 A |
| Connected Load | 1440 W |
| Plug Type | NEMA 5-15P (3-prong) |
| Power Cord Length | 67 inches total |
| Power Cord Install Length (from unit edge) | Approx. 47 1/4 inches to left or right when facing door |
| Inlet Hose Length | Approx. 65 inches |
| Outlet Hose Length | 74 3/4 inches |
| Delay Start | Up to 24 hours (some Bosch docs list “no delay” as a separate option setting; retailer specs show 24 h delay wash) |
| Status Indicator | End-of-program audible signal |
| Digital Countdown Display | Yes |
| End of Cycle Sound | Yes |
| Salt Refill Indicator | Yes (where water softener used) |
| Rinse Aid Indicator | Yes |
| InfoLight® | Red floor beam to indicate running cycle |
| TimeLight® | No |
| Child Lock | No |
| Safety Device | Triple water protection, 24/7 AquaStop® Plus |
| Technologies / Features | PrecisionWash® wash system; PureDry® energy-efficient drying system (safe for plastics); RackMatic® upper rack height adjustment; Flexible 3rd Rack with expandable wings and adjustable tines; EasyGlide™ rack system on all racks; 24/7 AquaStop® Plus leak protection; Home Connect® Wi‑Fi connectivity; Concealed heating element; Stainless steel toe kick; Adjustable feet. |
| Country of Origin | Germany (DE) |
| UPC / EAN | UPC 825225974130; EAN 4242005481910 |
| Optional Accessories | Junction Box: SMZPCJB1UC; Drain Hose Extension Kit: SGZ1010UC; Edge Protector + Power Cord Clip Install Kit: SMZEPCC1UC; Other listed accessories: SGZ1010UC, SMZ5000 (varies by retailer). |
WARRANTY
| 1 YEAR PARTS & LABOUR WARRANTY | Yes |
