Description
Bosch 500 Series Range Hood 30″ Width HCB50651UC
New Open Box
| Specification | Value |
|---|---|
| Brand | Bosch |
| Series | 500 Series |
| Model | HCB50651UC |
| Product Type | Wall-mounted chimney range hood |
| Style | Chimney style canopy hood |
| Venting Type | Convertible (ducted or recirculating with accessory kit) |
| Blower Type | Internal, centrifugal |
| Capacity (CFM) | 600 CFM |
| Noise Level | Approx. 2.0 – 11.5 sones (up to about 9.9–11.5 sones on high, depending on source) |
| Number of Fan Speeds | 4-speed (4-stage) |
| Operating Mode | Exhaust (ducted) / Recirculation (with optional kit) |
| Mounting Type | Wall mount |
| Range Hood Type | Wall-mounted canopy chimney hood |
| Color / Finish | Stainless steel |
| Control Type | Electronic touch controls with LCD display |
| Display Type | LCD |
| Clean Filter Reminder | Yes (indicator on LCD display) |
| Filter Cleaning Indicator | Yes |
| Grease Filter Type | Multilayer cassette / stainless steel mesh |
| Grease Filter Material | Washable stainless steel |
| Dishwasher Safe Filters | Yes |
| Charcoal / Odor Filter Option | Yes, charcoal replacement filters available (for recirculation) |
| Number of Lights | 2 |
| Light Type | Halogen |
| Light Specs | 2 × halogen, 12 V, 20 W max, G-4 base |
| Light Control Type | Continuous / electronic |
| Total Lamp Power | Approx. 40 W total |
| Connectivity | No Home Connect (not Wi‑Fi connected) |
| ADA Compliant | No |
| Energy Star Rated | No |
| Width | 30 inches |
| Depth | 19 11/16 inches (≈ 19.69 in) |
| Minimum Overall Height | 27 1/16 inches |
| Maximum Overall Height | 45 13/16 inches (≈ 45.81 in) with chimney extended |
| Appliance Dimensions (H × W × D) | 27 1/16 – 45 13/16 in × 30 in × 19 11/16 in |
| Width Class | 30-inch class (24″–30″ width category) |
| Duct Size | 8-inch round |
| Ventilation Direction | Vertical discharge |
| Exhaust Vent Location | Top (vertical ducting; some retailers also list top/rear generically) |
| Required Distance Above Electric Cooktop | Typically 24 inches minimum (per installation guides) |
| Required Distance Above Gas Cooktop / Range | Typically 27–30 inches (24–30 in range often quoted by retailers) |
| Recommended Height Above Cooktop (Range) | 24 – 30 inches |
| Height Above Cooktop (cm) | 60.96 – 76.20 cm |
| Motor Location | Integrated motor in hood chimney |
| Number of Motors | 1 |
| Motor Included | Yes |
| Connection Rating / Max Wattage | Approx. 530 W |
| Voltage | 110–120 V |
| Frequency | 60 Hz |
| Amps | 15 A (typical circuit requirement) |
| Plug Type | No plug (hardwired connection required) |
| Range Hood Features (Summary) | Removable grease filters, dishwasher-safe stainless steel filters, halogen lighting, timer, clean-filter reminder, convertible venting |
| Timer | Built-in timer, 1–60 minutes |
| Automatic Heat Sensor | Yes, blower automatically switches to high speed if excessive heat is sensed |
| Audible Tone | Yes, audible tone when select controls are pressed |
| Positioning | Stationary wall-mounted canopy |
| Maximum CFM | 600 CFM (integrated blower included) |
| Sones Rating Range | Approx. 2.0 – 11.5 sones (varies by speed) |
| Noise Level Category | Standard (high on maximum speed) |
| Net Weight | Approx. 43 – 54 lb (varies slightly by listing; manufacturer documentation typically ~54 lb) |
| Shipping / Gross Weight | Approx. 61 lb (where listed) |
| Product Packaging Dimensions (H × W × D) | Approx. 26 3/8 in × 34 1/2 in × 18 in (varies slightly by retailer) |
| UPC / GTIN | 825225909040 |
| Approval Certificates | UL, cUL |
| Outdoor Use Approved | No |
| Country / Region Notes | Model and specs commonly listed identically on U.S. and Canadian retailer sites; no capacity in cu ft (not a laundry product) |
| Included Accessories | Stainless steel grease filters, halogen bulbs (per most retailer listings) |
| Optional Accessories | Recirculation kit, duct extension kit for 9’–12′ ceilings, charcoal filters (sold separately) |
| Typical Ceiling Compatibility | Standard installation; duct extension accessory kit available for approx. 9’–12′ ceilings |
WARRANTY
| 1 YEAR PARTS & LABOUR WARRANTY | Yes |
